SeikoLSWN-8BL-3 Heavy Duty Walking Foot Lockstitch Machine

Also listed as LSWN-8BL, LSWN8BL3, LSWN 8BL 3, LSWN-8BLV-3 and LSWN-8BL-3-TA

A single needle walking foot lockstitch machine for medium to heavy fabrics, leather, vinyl and laminated material. It runs at high speed while a compound feed keeps thick layers moving together.

Built for Automotive interiorsHome textiles and furnitureTechnical textiles

Price in AED on request. We reply with the price and delivery time, usually within one working day. Machines for a whole line are quoted together.

Seiko LSWN-8BL-3 Heavy Duty Walking Foot Lockstitch Machine
  • 2,800Speed, stitches per minute
  • 10mmStitch length, maximum
  • 33.2mmNeedle bar stroke
  • 44.5kgNet weight, head only
  • 5,000+factories supplied by Al Borj in the Middle East and Africa

The LSWN-8BL-3 up close

1 photo · tap to enlarge

The Seiko LSWN-8BL-3 in 30 seconds

What it is

The Seiko LSWN-8BL-3 is the single needle model of the LSWN series, with a compound feed, walking foot and large vertical axis hook.

Who it's for

Upholstery, tarpaulin, awning, bag and luggage factories and workshops in the UAE, the GCC and Africa.

Why this model

Choose it for long, heavy seams: Seiko lists up to 2,800 stitches per minute and a 10 mm stitch length.

Setting up a factory line with the LSWN-8BL-3

We quote by the line and stay with you after the machines are running.

  1. 01

    Factory assessment

    We look at what you make, your daily output target and your floor, then recommend the machine mix for each line.

  2. 02

    Quote by the line

    Machines, delivery and installation in one AED quotation.

  3. 03

    Installation and training

    Our technicians set up every machine at your factory and train your operators on site.

  4. 04

    Parts and maintenance

    Spare parts and annual maintenance contracts for every machine on the floor.

What the LSWN-8BL-3 does on a factory floor

Seiko LSWN-8BL-3, Heavy-Duty Walking Foot Machine

Feed

Layers pulled through together

Seiko fits a compound feed and walking foot. The walking foot lifts 3 to 6 mm, standard 4 mm, and a thumb screw on top adjusts the pressure force.

On the factory floorTop and bottom layers move together, so long heavy seams stay flat and even.

Seiko LSWN-8BL-3, Heavy-Duty Walking Foot Machine

Hook

A 2.0 times hook with a safety clutch

The large vertical axis hook has automatic lubrication. A safety clutch prevents the hook from being damaged.

On the factory floorThe larger hook holds more bobbin thread, so the operator stops less often to change it.

Seiko LSWN-8BL-3, Heavy-Duty Walking Foot Machine

Built-in features

Bobbin winder and long stitch

A built-in bobbin winder lets the operator wind a bobbin while stitching. The maximum stitch length is 10 mm, and a feed adjusting dial sets stitch length.

On the factory floorWinding a bobbin while stitching means a run does not stop just to refill.

  • Versions

    The LSWN-8BLV-3 adds a synchronized binder, and the LSWN-8BL-3-TA is the thick thread version.

Seiko LSWN-8BL-3 specifications

Stitching

NeedlesSingle needle
Maximum speed2,800 s.p.m.
Maximum stitch length10 mm
Needle systemDPx17 (#22) or 135x17 (#140)
HookLarge vertical axis hook (2.0 times)
Walking foot lift3 to 6 mm (standard 4 mm)

Machine

Working space518 x 177 mm
Presser foot clearance16 mm by knee, 8.5 mm by hand
Needle bar stroke33.2 mm
LubricationSemi-automatic
Net weight, head only44.5 kg

Figures from the Seiko catalogue, 2026. Seiko may change specifications without notice. Speed depends on thread, material and operation.

Included with every Al Borj machine

  • Delivery across the UAE and the wider Middle East and Africa
  • Installation at your factory
  • Operator training on site
  • Genuine spare parts
  • Annual maintenance contracts (AMC)
Catalogue Seiko LSWN-8BL-3Full specifications from Seiko, PDF Download

Questions about the Seiko LSWN-8BL-3

Anything else, ask us on WhatsApp. We usually reply within one working day.

Ask on WhatsApp

Is the LSWN-8BL-3 the same as the LSWN8BL3?

Yes. Seiko writes LSWN-8BL-3, and people also type LSWN8BL3 or LSWN 8BL 3.

What is the TA version?

Seiko lists LSWN-8BL-3-TA as the thick thread version, with DPx17 #24 or 135x17 #180 needles.

Which is faster, the LSWN-8BL-3 or the LSWN-8BLV-3?

The LSWN-8BL-3 reaches 2,800 s.p.m. and the binder model LSWN-8BLV-3 reaches 2,500 s.p.m.

What is the price of the Seiko LSWN-8BL-3 in the UAE, Saudi Arabia, Oman, Bahrain, Kuwait or Qatar?

It depends on the quantity, the options and where it is delivered. For a factory line we quote all the machines together. Send your city and quantity on WhatsApp or through the enquiry form and we reply with the AED price and delivery time, usually within one working day.

Can you equip a whole line, not just this machine?

Yes. Tell us what you make and your daily output target. We recommend the machine mix for the line and can visit your factory for an assessment first.

Do you deliver the Seiko LSWN-8BL-3 and train our operators?

Yes. We ship from Sharjah across the UAE, the GCC and Africa, and we have offices in the UAE and Ghana. We install the machine at your factory and train your operators, then support you with spare parts and service.

Can I see the Seiko LSWN-8BL-3 before I buy?

Book a visit to our showroom in Industrial Area 4, Sharjah. Tell us the model first so we can confirm what we can show you, and bring a sample of your own material.
