A post bed lockstitch machine for shoes and shaped leather work.
The Jin NA-35 Series sews on a raised post rather than a flat bed, so a shaped piece can be turned around the needle. Juki publishes three builds: the NA-35DUT-1, one needle with wheel feed and needle feed and digital stitch length control, the NA-35UT-1, one needle with a roller presser, and the NA-35UT-2, two needle with a roller presser.
Juki states that the series is best suited to sewing shoes, that the top and bottom wheel feed holds the material and keeps the needle entry in view on multi layered parts, and that digital stitch length control is supported on the NA-35DUT only. Juki lists a flip up ruler, an LED light under the arm jaw, a control box integrated with the machine head and a USB port as standard.
Specification published by Juki
Model names
NA-35DUT-1, NA-35UT-1 and NA-35UT-2
Type
1 needle (NA-35DUT-1 and NA-35UT-1), 2 needle (NA-35UT-2)
Max. sewing speed
3,000 stitches per minute (1 needle), 2,000 stitches per minute (2 needle)
Max. stitch length
7 mm (NA-35DUT-1), 5 mm (NA-35UT-1), 3 mm (NA-35UT-2)
Needle bar stroke
38 mm
Feed system
Top and bottom wheel feed and needle feed (NA-35DUT-1). Top and bottom wheel feed (NA-35UT-1 and NA-35UT-2)
Lift of the presser foot
By hand 7 mm, by knee 10 mm
Hook
Vertical axis 2.0 fold capacity hook
Needle
DP×5 #16 (#11 to #21), 135×5 Nm100 (Nm75 to Nm130)
Stitch length adjustment
Digital stitch length (NA-35DUT-1), by stitch dial (NA-35UT-1 and NA-35UT-2)
Lubrication
Automatic, hook only
Lubricating oil
Machine Oil No.18, ISO VG18 equivalent
Main motor output
750 W
Distance from needle to machine arm
285 mm by 255 mm (NA-35DUT-1), 285 mm by 250 mm (NA-35UT-1 and NA-35UT-2)
Power consumption
401VA
Weight of the machine head
62 kg
Al Borj Machinery in Sharjah supplies Jin machines with installation, operator training and annual maintenance across the UAE, Saudi Arabia and the wider GCC. Send us the part you need to sew and we will quote the right build.
