Jack JK-8009HF, Power-Saving 4-Needle Interlock with Thread Trimming

A 4-needle chainstitch machine for waistbands and parallel rows of stitching.

The Jack JK-8009HF-04064-254P is a multi-needle cylinder bed chainstitch machine set up with 4 needles and 8 threads. A machine in this class lays several parallel rows at fixed distances in one pass, which is how a jeans waistband, an elastic band or a shirt front gets its even rows.

Jack states that the JK-8009HF suits sewing the waistband on jeans. Jack states that the series takes a puller so that thick and awkward material feeds evenly, that the distance between the needles can be changed, and that releasing the hook holder makes threading easier. Jack lists attaching elastic, attaching ribbon and shirt fronting among its uses, and publishes the series with automatic central lubrication. Jack states that the automatic thread trimmer cuts at the end of the seam and that the automatic foot lifter then raises the presser foot, and it marks the builds carrying those two functions with the UTL suffix.

Key features

• 4 needles and 8 threads, cylinder bed
• Distance between the needles can be changed
• Gear puller for thick and awkward material, the P in the model code
• Hook holder releases for easier threading
• Automatic central lubrication
• Jack marks the builds with an automatic thread trimmer and automatic foot lifter UTL

Specification published by Jack

Specification published by Jack for this build. Jack publishes the same machine from 4 up to 25 needles, so the needle count, the gauges and the puller type all change the model code. Send us the operation and the row spacing you need and we will confirm the build and the current specification before you order.

Download the 8009 catalogue (PDF)

Al Borj Machinery is Sharjah's authorised Jack distributor. We deliver, install, train your operators and service the machine across the UAE, Saudi Arabia and the wider GCC.
