Barudan Catalogue and specifications

Barudan BEKS-HLCLZ catalogue (PDF)

Covers BEKS-HLCLZ1101, BEKS-HLCLZ1102, BEKS-HLCLZ1104 and BEKS-HLCLZ1106

Barudan's catalogue for the BEKS-HLCLZ triple-combination machines, which do standard embroidery, chenille and lockstitch zigzag from one head layout. Uniform badge makers and shops producing varsity lettering, patches and home textile designs cover all three looks without changing machines.

Download the catalogue (PDF, 2.6 MB) Barudan BEKS-HLCLZ: photos and quote

2 pages, Barudan Co., Ltd. catalogue, Al Borj edition, 2026. Free to download, with our contact details on the first and last page. For the AED price, delivery and installation, ask us on WhatsApp; we reply within one working day.

Barudan BEKS-HLCLZ catalogue, page 1: the Triple Combination series, the BEKS-HLCLZ1101, specifications and B-NET software

What the Barudan BEKS-HLCLZ catalogue covers

Two pages in English: the BEKS-HLCLZ1101 with its specifications and Barudan's B-NET software, then the 6-head BEKS-HLCLZ1106 and its embroidery functions. The range comes with 1, 2, 4 or 6 heads and an 800 × 850 mm or 800 × 880 mm field.

Barudan lists chenille at 200-650 rpm against 200-1000 rpm for standard embroidery, which matters when you plan output per shift. Al Borj supplies, installs and services the BEKS-HLCLZ from Sharjah and Accra.

Machine type: Triple-combination embroidery machine: standard, chenille and lockstitch zigzag.

Needles a head: 11 needles (standard embroidery), 6 needles (chenille chain stitch)
Embroidery area: 800 x 850 mm or 800 x 880 mm
Speed, standard embroidery: 200-1000 rpm
Speed, lock stitch zigzag: 200-900 rpm
Power supply: 1-phase AC200V-240V or 3-phase AC200V-415V
Power consumption (maximum): 1.0 kW (1, 2, 4-head models); 1.5 kW (6-head model)
